More than 20 years of R&D Experience
AERV series time relays are widely used in industrial,residential,commercial and other fields,requiring time-related control.
Production Selection Guide：
Explanation
Type
Time Range
On Delay
220V AC
24V AC/DC
DIN-Rail
Pcs.Box
Time Relays
AERV-03
0,1-3.sec
●
20
AERV-06
0,1-6.sec
AERV-12
0,1-12.sec
AERV-30
0,1-30.sec
AERV-60
0,1-60.sec
AERV-03D
0,1-3.min
AERV-06D
0,1-6.min
AERV-12D
0,1-12.min
AERV-30D
0,1-30.min
AERV-60D
0,1-60.min
Multifunctional Timer
AERV-08
0,1-100.hour
Star-Delay Timer
AERV-YU
0.1-30 sec.(Y)
10-500ms(Y→△)
Technical Parameters：
Dimensions
23mm
Protection Class
IP20
Weight
65g/Pcs
75g/Pcs
Operating Voltage
220VAC/24VDC
Operating Range
150-260VAC, 24VDC±10% (Other customizable)
Power Consumption
<4VA
Output Contact
5A/250V AC (Resistive Load)
Ambient Conditons/Humidity
-20℃.....+55℃；85%
Mounting
DIN-Rail Mounting/Screw Terminals
Outline dimension & WiringDiagram：
